Mirabelle AI Assistant

Overview

Mirabelle is a conversational APS (Advanced Planning & Scheduling) assistant built directly into the ForecastAI/Mirabelle application. It translates natural-language questions into read-only ClickHouse queries, renders the results as charts, tables, or KPI cards, and provides a business-friendly explanation — all within a side panel that stays available while you work.

Opening the panel

DesktopMobile

Click the sparkle button on the right edge of the screen. The panel slides in from the right.

Tap the sparkle icon in the top toolbar. The panel opens as a full-width overlay.

Panel layout

The panel is organised into three tabs:

Tab	Purpose
Chat	Natural-language Q&A with charts, tables, and explainability
Exceptions	Preserved legacy alert list with severity pills and approve/dismiss actions
Help	Built-in guide with capabilities, sample prompts, and privacy notes

Resizing

The panel width is adjustable between 280 px and 720 px:

• Drag the left border handle to resize continuously.
• Double-click the handle to reset to the default width (320 px).
• Your preferred width is persisted in localStorage across sessions.

---

Chat Tab

Asking a question

1. Type your question in the input area at the bottom.
2. Press Ctrl + Enter (or Cmd + Enter on macOS) to send — or click the send arrow.
3. Mirabelle runs the full retrieval → SQL generation → validation → execution → explanation pipeline and streams the answer back.

Quick-prompt cards

When the chat is empty, Mirabelle shows five canonical APS questions as clickable cards:

Card	Question sent
Expiry next week	"What products are at risk of expiry next week?"
Compare scenarios	"Compare inventory risk between Baseline and Growth scenario."
Service level Spain	"Why did service level drop in Spain?"
Top forecast errors	"Show top 20 items with largest forecast error."
Allocation shortages	"Which allocations are causing shortages?"

Click any card to submit it instantly.

Multi-turn conversation

Mirabelle keeps the last 6 conversation turns in memory for the current session. This means you can ask follow-up questions without restating context:

Follow-up refinement

1. You: "Show top 20 items with largest forecast error"
2. Mirabelle: (returns bar chart + table)
3. You: "Only for Spain"
4. Mirabelle: (narrows results to Spain using context from turn 1)

Conversation history is in-process only (never written to disk) and is automatically cleared on logout or server restart. The session TTL is 60 minutes of inactivity.

---

What Mirabelle Can Answer

Intent	Output type	Example prompt
Direct lookup	Table / KPI cards	"What is the current safety stock for item X at site Y?"
Trend over time	Line chart	"Show forecast accuracy trend over the last 12 weeks"
Top-N ranking	Bar chart + table	"Top 20 items with largest forecast error"
Distribution by category	Bar chart	"Distribution of stock days by country"
Scenario comparison	Side-by-side bars	"Compare inventory risk between Baseline and Growth"
Pipeline comparison	Bar chart	"Compare supply projections for pipeline A vs B"
Why-question diagnostics	Table + explanation	"Why did service level drop in Spain?"
Forecast accuracy review	Bar chart	"Show forecast accuracy by product category"
Expiry risk	Table	"What products are at risk of expiry next week?"
Capacity bottleneck	Table or bar chart	"Where are the supply bottlenecks?"
Allocation shortage	Table	"Which allocations are causing shortages?"
Conversational refinement	Narrowed results	"Only for Spain" (as a follow-up)

Drill-down navigation

When Mirabelle's result table contains a unique_id, item_id, or site_id, each row shows a link. Click it to navigate directly to the detail view for that item-site combination. The target page depends on the query topic:

Query topic	Target detail tab
Forecast consumption / netting	Netting tab
Service level / fill rate	Pipelines view
Outliers / anomaly detection	Outlier Analysis tab
Supply / inventory	Supply view

---

Explainability

Every assistant reply includes a "How was this answered?" expander. Click it to reveal:

Section	Description
Tables	Blue chips listing every ClickHouse table used in the query
Business concepts	Purple chips listing the APS concepts that matched (e.g. service level, stock days)
SQL	The full, read-only SQL statement in a monospaced block
Generation stats	Number of generation attempts and total response time in milliseconds

Self-correction loop

If the first generated SQL fails validation or execution, Mirabelle automatically retries (up to 2 attempts by default). The attempts counter tells you how many tries were needed.

---

Exceptions Tab

The Exceptions tab preserves the legacy Alerts panel functionality.

Features

• Severity summary pills — click a pill (critical, high, medium, low) to filter to that severity; click again to clear the filter.
• Status filter — toggle between Open, Approved, Rejected, and All.
• Batch-run refresh — click the refresh button to re-evaluate all alert rules.
• Approve / Dismiss — each alert row has action buttons to approve or dismiss it.
• Drill-down — click an alert's item name to navigate to the Series detail view.

---

Help Tab

The Help tab is a built-in quick-reference covering:

• What Mirabelle can do (capabilities list)
• Sample prompts to try
• Architecture overview (how retrieval → SQL → execution works)
• Privacy and security notes

No internet access is required — the help content is part of the application.

---

Privacy & Security

Fully on-premise

Mirabelle is designed for on-premise deployment with zero external API calls.

Concern	How Mirabelle handles it
Cloud LLM	Not used. All inference runs locally via Ollama on the server.
External API calls	None. The entire stack (LLM, vector store, data warehouse) runs inside your infrastructure.
SQL safety	Generated SQL is restricted to SELECT / WITH only. DDL, DML, and all destructive keywords are blocked by the validator.
Conversation history	Held in-process only — never persisted to disk. Cleared on logout, session timeout (60 min), or server restart.
Data access	The SQL executor uses a read-only connection. Mirabelle cannot modify, insert, or delete data.
LanceDB index rebuild	Requires admin role. Triggered via POST /api/mirabelle/index.

---

Technology

Layer	Technology	Notes
Local inference	Ollama	Serves the LLM on-prem at localhost:31434 by default
LLM	Qwen2.5-Coder 7B (quantised)	Configurable via MIRABELLE_LLM_MODEL env var
Vector store	LanceDB	On-disk, embedded; stores schema, glossary, SQL examples, sample values
Embeddings	sentence-transformers/all-MiniLM-L6-v2	384-dim, ~80 MB, CPU-friendly. Falls back to hash vectors if unavailable.
Data warehouse	ClickHouse	Read-only queries over the APS schema
Backend	FastAPI	Exposes /api/mirabelle/* endpoints
Frontend	React + Plotly.js	MirabellePanel component with inline chart rendering

Pipeline overview

User question
  │
  ▼
┌─────────────────────────┐
│  Hybrid retriever        │  Keyword extraction + LanceDB semantic search
│  (retriever.py)          │  + ontology synonym boost
└────────┬────────────────┘
         │  context bundle
         ▼
┌─────────────────────────┐
│  SQL generator           │  Qwen2.5-Coder 7B via Ollama /api/chat
│  (sql_generator.py)      │  JSON-mode output: {sql, chart_type, …}
└────────┬────────────────┘
         │  SQL
         ▼
┌─────────────────────────┐
│  SQL validator           │  SELECT/WITH-only guard
│  (sql_validator.py)      │  Blocks DDL/DML keywords
│                          │  Column validation against schema_metadata.json
└────────┬────────────────┘
          │  valid SQL
          ▼
┌─────────────────────────┐
│  Deterministic fixers    │  _fix_sql_placeholders()
│  (service.py)            │  _fix_sql_interval_funcs()
│                          │  _fix_sql_demand_corrected()
└────────┬────────────────┘
         │  valid SQL
         ▼
┌─────────────────────────┐
│  ClickHouse executor      │  Read-only execution, 500-row limit
│  (executor.py)            │  Retries on failure (max 2 attempts)
└────────┬────────────────┘
         │  rows + columns
         ▼
┌─────────────────────────┐
│  Explainer + Chart advisor│  LLM-generated business summary
│  (explainer.py,           │  + automatic chart_type selection
│   chart_advisor.py)       │
└────────┬────────────────┘
         │  answer + chart + table
         ▼
      Frontend

---

Troubleshooting

The Mirabelle status indicator (at the top of the Chat tab) shows the current health of the stack. Common issues and fixes:

Symptom	Status indicator	Resolution
Ollama not running	ollama_available=false	Start the Ollama service: ollama serve
LanceDB index missing	lancedb_ready=false	Rebuild the index: POST /api/mirabelle/index (requires admin role)
Embedding fallback active	embedding_fallback=true	Install sentence-transformers: pip install -r requirements.txt
Generation failed after retries	Error: "could not generate after 3 attempts"	Check Ollama logs; re-pull the model: ollama pull qwen2.5-coder:7b-instruct-q3_K_M
Slow first response	N/A	Expected — the model cold-loads into GPU/CPU memory on the first request (~20s with GPU, ~70s CPU-only). Subsequent responses are fast.
Model not pulled	model_warning in status	Run ollama pull qwen2.5-coder:7b-instruct-q3_K_M or set MIRABELLE_LLM_MODEL to an available model
Index pending indicator	"index pending" in status bar	The index is building on first chat. Wait a few seconds, or trigger manually via the API.

Ollama URL override

By default Mirabelle connects to http://localhost:31434. If your Ollama instance runs on a different port or host, set the MIRABELLE_OLLAMA_URL environment variable.

LanceDB index rebuild

The index should be rebuilt whenever the APS schema changes (new tables, columns, or glossary entries). Use POST /api/mirabelle/index from an admin session, or run python -m files.mirabelle.indexer build on the server.
